cyclone50/100/200/300/600
Laser Obstacle Cleaning Instrument for Power Grid
Working principle
● Laser Obstacle Cleaning Equipment for Foreign Objects in Power Grid
● Laser high energy instantaneous ablation of foreign bodies wound on high voltage lines without damaging transmission lines
● Wide range of products, power 50-600W
● Effective Distance of 30-240 M
● Non-destructive to conductors, simple and controllable operation
● Safe and fast, 5-10 seconds fuse foreign body
● Batteries can work for 2 hours at full power
● Adapt to a variety of operating environments: windy, rainy, snowy, night, etc.
Seven advantages
1. Wide range of products, 50-600w, 30-240m effective distance
2. No damage to conductor
3. Simple and controllable operation
4. Safe and fast, fusing foreign matters in 5-10 seconds
5. Battery can work for 2 hours under full load power
6. Adapt to a variety of operating environment: wind, rain, snow, night, etc.
7. Common foreign matter removal, such as kites, fishing lines, paper cloth, twine, beehives, bird nests and branches
Details
|
Product name
|
Cyclone 50
|
Cyclone 100
|
Cyclone 200
|
Cyclone 300
|
Cyclone 600
|
|
Size(mm³)
|
312*495*447
|
515*360*245
|
647*495*312
|
647*495*312
|
810*540*310
|
|
Weight
|
<3
|
20
|
30
|
35
|
45
|
|
Cooling mode
|
Air cooling
|
Air cooling
|
Air cooling
|
Air cooling
|
Air cooling
|
|
Power(W)
|
50
|
100
|
200
|
300
|
600
|
|
Wavelength(nm)
|
1080
|
1080
|
1080
|
1080
|
1080
|
|
Supply voltage
|
48V DC
|
24V DC
|
48V DC
|
48V DC
|
220V DC
|
|
Maximum power consumption(W)
|
50
|
300
|
800
|
900
|
4600
|
|
Humidity(%)
|
10-95
|
10-95
|
10-95
|
10-95
|
10-95
|
|
Laser grade
|
IV
|
IV
|
IV
|
IV
|
IV
|
|
Maximum working distance(m)
|
30
|
90
|
200
|
240
|
240
|
|
Pan tilt accuracy(*)
|
0.6
|
0.6
|
0.6
|
0.6
|
0.6
|
|
Fiber length(m)
|
3
|
3
|
3
|
3
|
3
|
|
Continuous full load working time(H)
|
2
|
2
|
2
|
2
|
2
|
|
Minimum / maximum operating temperature(°C)
|
-20-45
|
-20-45
|
-20-45
|
-20-45
|
-20-45
|
